Small size External Circular Antenna GPS&Glonass Antenna with Fakra
AGG-M4616-FA1
Small Size External Circular Antenna GPS&Glonass Antenna with Fakra

    The function of the GPS&Glonass receiving antenna is to transform the electromagnetic wave energy of the radio
signal from the satellite into a power source that can be picked up by the receiver electronics. Our GNSS antenna is
composed of ceramic ntenna body and active amplifier. It is packaged in a plastic shell, which is waterproof and
moisture-proof.

Product Description

NO.ParameterSpecification
1Range of Receiving Frequency (MHz)1575.42&1602±3MHz
2Center Frequency (MHz)
(with 30mmSpuareGND plane)
1575.42&1602±3MHz
3Band Width (MHz)(Return Loss≤-10dB)≥10
4V.S.W.R (in Center Frequency)≤1.5
5Gain (Zenith) (dBi typ)
(with 70mmSquare GND plane)
4.5
6Axial Ratio (with 70mm Square GND plan)3.0dB
7PolarizationRHCP
8Impedance (Ω)50
9Frequency Temperature Coefficient (ppm/ºC)0±10
10LAN Gain28±3 dB
11In Center Frequency≤2.0
12Noise Figure<2.0
13Supply Voltage3~5V
14Current Consumption12±1mA@3VDC
15Size46*16mm
16Mounting Screw
17Weight55g
18ConnectorFAKRA
19Cable1M
20Operating Temp.-40ºC~+85ºC
21Storage Temp.-45ºC~+85ºC
22Operating Humidity0%~95%
23Storage Humidity0%~95%
24Optional cable length2M,3M,5M or customized

Product advantages and characteristics
Features:
1.Murata acoustic meter filter, effective filtering noise
2.Infineon low noise LNA, output signal to noise ratio
3.High gain, low standing wave ratio, good reception
4.Imported ceramic body
5.Waterproof IP67 / IP68

Advantage:
1.IATF16949 quality management system standard
2.Certification: FCC CE ROHS2.0
3.Semi-automatic production ensures product consistency

Small Size External Circular Antenna GPS&Glonass Antenna with Fakra

Quality Standard
1. Inspection method (if the customer inspection is strict with the company, the OQC shall be based on the customer's
acceptance standard)
GB2828 inspection according to standard sampling table, normal inspection, one sampling, II
level plan.

Fatal/serious defect: AC=0 minor defect: AQLAC=1.0
Our company's inspection standard for full inspection, shipping standards for zero defects.
2. The above inspection standards / methods are different from customer standards, customer standards shall prevail.
3. Products shipped abroad must conform to the relevant national standards before shipment.
Small Size External Circular Antenna GPS&Glonass Antenna with Fakra
Production Testing Process
Small Size External Circular Antenna GPS&Glonass Antenna with Fakra

Small Size External Circular Antenna GPS&Glonass Antenna with Fakra
Company Capacity
     Delin comm Limited, is a professional enterprise with its own brand (DELINCOMM) and 28 years of experience in R&D,
production and sales.

      We focuses on the R&D and production of radar antenna, base station antenna, power antenna, GPS antenna,
GLONASS antenna, 5G antenna, 4G antenna, 2.4G antenna, WiFi Antenna, BT antenna, GSM antenna, DVB-T antenna,
WLAN antenna,GNSS antenna, various Combined antenna,GPS module, GNSS module, GPS antenna module,
GNSS antenna module,MOUSE receiver, NFC module, 4G module and 5G module, etc.


Small Size External Circular Antenna GPS&Glonass Antenna with Fakra
Common Problems

Sample cost issues
1. We will charge the sample fee and make the sample until you are satisfied
2. Freight is generally borne by the buyer, specific circumstances can be negotiated, specific specifications please contact us
3. Our products are national standard accessories, can be customized according to your needs

Product after-sales service
1. We not only pay attention to pre-sale guidance and product quality, but also pay more attention to after-sales service. If
you find any problems or need guidance after purchasing any of our products, please contact us.


Product Delivery
1. About delivery
1.1.We cooperate with many express delivery companies.In general, we follow the default expression in scope.If you have a
specific delivery, simply point it out or contact customer service.Otherwise, we will use our own default messenger.Please
check the shipping address and contact information before shipping.

2. Order delivery
2.1. Sample delivery time is about 3 days, and mass production cycle is 5-15 days
2.2. Emergency order processing, our company has emergency orders to speed up processing process, will be completed
for you in time.
