Product Specification
Features and Benefits
Item | Specification | ||
LTE MIMO | Frequency Range | Main:824-960MHz/1710-2690MHz | |
Vice:1800-2690MHz | |||
VSWR | <=3.0 | ||
Efficiency | >=40%(Average) | ||
Polarization | Linear | ||
Impedance | 50Ω | ||
Main and auxiliary antenna isolation | >=10dB | ||
WIFI MIMO | Frequency Range | WIFI1:2400-2485MHz/5000-5900MHz | |
WIFI2:2400-2485MHZ | |||
VSWR | <=2.0 | ||
Efficiency | >=40%(Average) | ||
Gain | >=-4dBi | ||
Polarization | Linear | ||
Impedance | 50Ω | ||
BT | Frequency Range | 2400-2485MHz | |
VSWR | <=2.0 | ||
Efficiency | >=40%(Average) | ||
Gain | >=-4dBi | ||
Polarization | Linear | ||
Impedance | 50Ω | ||
Structure | T-BOX Board size | 140mm×75mm | |
Antenna | 55.8mm×26.5mm×14.5mm | ||
Scaffold material | PC/ABS | ||
Antenna material | Stainless steel 301 | ||
Installation method | Buckle type | ||
Working environment | Operating temperature | -40ºC~+85ºC | |
Relative humidity | 95% | ||
shock | 5Hz-200Hz Per axis 8 hours | ||
Surroundings | Meet ROHS |
Features and Benefits
- Strong R&D team which is dedicated to research,design,analyze and test innovative antenna systems
- Professional and efficient mechanical and RF simulation toolis to make sure the perfect antenna performances
- One stop solution to design and manufacture all kinds of antennas for industrial and automotive applications
- Provided quad band,muti-function module,AM/FM short whip,embedded BT antenna,stealth GSM and GPS antenna,and the TPM antenna,RFID antenna
- Customeized and standard antennas design and manufacture
- Strict quality control and end to end process
Applications
CTW is founded in the end of 2013. We a aglobal professional provider for connectors, antennas and wire harness.
We are dedicated to providing innovative solutions & high quality products for industrial, telecommunications & networking, military, medical and automotive markets.
Global professional provider for antennas ,cable assembly, precision parts & assembly, industrial connectors.
- Industrial RFID antenna
- Asset tracking external /internal antenna
- Automotive muti-function antenna
- Wireless alam,security and monitoring systems
- Vehicle tracking systems
CTW is founded in the end of 2013. We a aglobal professional provider for connectors, antennas and wire harness.
We are dedicated to providing innovative solutions & high quality products for industrial, telecommunications & networking, military, medical and automotive markets.
Global professional provider for antennas ,cable assembly, precision parts & assembly, industrial connectors.
Professional & experienced R&D/Engineering team who are dedicated on research and development.
Rigorous and controlled manufacturing process and excellent quality system.
R&D Strategy & Capability
*Grow revenue and profit by innovation by providing new technology and competitive new design to customer
*Build strong research and development team
*Re-investment in R&D
*Completed and competitive R&D system
*High level design analysis capability (FEA/Moldflow/HFSS)
*Completed laboratory lab
