698-2700MHz Indoor Wall Mounted Antenna/LTE 4G Directional Panel Antenna (GW-IWMA70277d)

Product Feature:
* Elegant appearance, simple installation, stable performance.
* Good performance in anti-vibration and resistant to aging.
* Fit for installation for Aluminum ceiling and Gypsum Ceiling.


ELECTRICAL
Frequency Range698-960/1710-2700-MHz
Bandwidth262/990-MHz
Gain7-dBi
 Intermodulation IM3 ≤-107-dBm  (2W)
VSWR≤2.0
PolarizationVertical
Max power100 -W
Nominal Impedance50 -Ω




MECHANICAL
Connector­­­N female or customized
Antenna Dimension         208*178*45-mm
Weight0.5-kg
Rated Wind Velocity60-m/s
MountingWall Mount

Recommended Accessories:
1) Donor antenna: Log Periodic Antenna (9dBi,806-960/1710-2700MHz)
2) Service antenna: Omni Ceiling Antenna (3dBi,806-960/1710-2700MHz)
3) 5D-FB coaxial cable with connecter (Cable length optional)


Method of Installation:
The booster is fixed onto the wall through expansion bolts.
A.  Drill holes in the selected place and install expansion bolts.
B.  Align the holes with the expansion bolts, place flat washers, spring washers, and nuts in turn, and tighten the nuts to fasten the installing support.
C. Place the booster on and fasten it.
D. Connect cables and power cables to the booster respectively.
E. After installing the booster as described above, power on the booster to check the operation status.


Connection:
A.  BTS Port: donor antenna cable is connected with Outdoor Port;
B.  MS Port: service whip antenna is connected with Indoor Port;
C.  DC IN connected with Power adaptor.
